Let's bring all your creative ideas to life with AnkerMake M5C.
Whether you're a beginner or a pro, this all-new printer is designed to be easy to use while still delivering the quality you desire—at the speed you can only imagine.
Printing Parameters | ||
---|---|---|
M5C | M5 | |
Print Size | 220×220×250 mm³ | 235×235×250 mm³ |
Print Speed | 500 mm/s | 500 mm/s |
Print Acceleration | 5000 mm/s² | 5000 mm/s² |
Benchy Print (Max) | 17 Min | 17 Min |
Filament | 1.75 mm | 1.75 mm |
Plate Temperature (Max) | 100℃ | 100℃ |
Printing Features | ||
M5C | M5 | |
One-Click Button | Y | N/A |
Smart Experience | ||
Camera (Video Streaming) | N | Y |
AI Recognition | N | Y |
Time-Lapse Videos | N | Y |
Extrusion | ||
Hotend | All-Metal | PTFE |
Nozzle | Brass, 0.4 mm | Brass, 0.4 mm |
Extrusion Distance | Direct Extrusion | Direct Extrusion |
Extrusion Flow | 35 mm³/s | 24 mm³/s |
Hotend Tempreture (Max) | 300℃ | 260℃ |
Auto-Leveling | 7×7 Point | 7×7 Point |
Screen | N | 4.3-Inch Touch Screen |
PEI Soft Magnetic Plate | Y | Y |
Multi-Material Support | ||
PLA | Y | Y |
PETG / PET | Y | Y |
ABS | Y | Y |
TPU | Y | Y |
PA | Y | N/A |
PLA-CF | Y | Y |
PETG-CF | Y | Y |
PA-CF | Y | N/A |
Electronics and Software | ||
M5C | M5 | |
Power | 100-240V AC, 50-60Hz | 100-240V AC, 50-60Hz |
Power Consumption | 350W, | 350W, |
Connections | WiFi, Bluetooth, USB-C | WiFi, Bluetooth, USB-C |
Storage | 8 GB EMMC, | 8 GB EMMC, |
Method of Interaction | Button, App, | Button, App, |
CPU | XBurst® | Dual XBurst® (1.2GHz) + XBurst®0 (240MHz) |
Slicer | AnkerMake Slicer, Prusa, Cura | AnkerMake Slicer, Prusa, Cura |
