Schulz Air Dryer Non-Cycling Compressed 20 CFM 232 PSI 115V 1-Phase New - ADS-20
The Schulz non-cycling compressed air dryers have been developed for applications with inlet and room temperatures up to 100 °F. Removable panels facilitate easy and quick access to internal components. With an integrated electronic panel, this dryer is an extremely cost-effective option. Select the best option for your company.
Features
-
The ADS Schulz line of air dryers was designed to facilitate inspection and maintenance operations. The panels are easily removable and allow immediate access to internal components. ADS Schulz dryers are equipped with a quick-disconnected automatic drain valve which does not require any special tools for maintenance and cleaning.
-
The dryer’s operation is monitored by an electronic controller The dryer’s operation is monitored by an electronic controller which digitally indicates the temperature and dew point, controls the drain valve through a timer, and the condenser fan through a probe. The refrigerant is circulated through the system using high-efficiency compressors. These compressors have totally new design that brings low levels of power consumption and high dependability.
-
ADS Schulz dryers are designed to match the displacement of the air compressors, consequently, it is not necessary to oversize the dryer, resulting in savings in energy consumption.
-
ADS Schulz dryers have excellent performance, even in situations where ambient and inlet temperatures are elevated.
Specifications
| Model | ADS-20 |
|---|---|
| Flow (CFM, l/min, m³/h) | 20 / 566 / 34 |
| Connections | 1/2" NPT-F |
| Nominal Air Pressure | 100 PSI |
| Max. Air Pressure | 232 PSI |
| Voltage | 115V |
| Frequency | 60 Hz |
| Nominal Amp | 2.7A |
| Wire | 14 GA |
| Refrigerant Type | R134A |
| Dimensions (H x W x L) | 18.11/16 x 14.9/16 x 18.11/16 in. |
| Weight | 55 lbs. (25 kg) |
Product Manual
What Our Experts Think
- Compact and Efficient: The Schulz ADS-20 Air Dryer provides 20 CFM of drying capacity, making it an excellent choice for smaller industrial and commercial applications where efficient moisture removal is essential.
- High Pressure Capability: With the ability to handle pressures up to 232 PSI, the ADS-20 is designed to perform reliably in high-pressure environments, ensuring clean, dry air for sensitive equipment.
- Non-Cycling Technology: Featuring non-cycling operation, this air dryer provides continuous performance without interruptions, offering consistent dry air for optimal system performance.
- Energy Efficient: Powered by 115V 1-phase electricity, the ADS-20 operates with low energy consumption, helping reduce operating costs while maintaining high efficiency.
- Durable and Reliable: Built with high-quality materials, the ADS-20 is designed to provide long-term, trouble-free operation, ensuring minimal maintenance and maximum reliability.
Q&A
Q: What is the Schulz ADS-20 Air Dryer?
A: The Schulz ADS-20 is a non-cycling air dryer designed for compressed air systems, offering a 20 CFM capacity and operating at 232 PSI with a 115V 1-phase power supply.
Q: Who is this air dryer suitable for?
A: Ideal for smaller industrial applications, workshops, or businesses that need efficient moisture removal from compressed air systems to protect tools and equipment.
Q: What are the dimensions of the air dryer?
A: Dimensions: [Insert dimensions]. Compact yet powerful, designed for efficient space usage in smaller setups.
Q: How do I maintain the air dryer?
A: Regularly check for debris or moisture buildup, replace filters when needed, and perform routine maintenance on the compressor and electrical components to ensure consistent performance.
Maintenance Tips
- Check Air Filter: Inspect and clean or replace the air filter regularly to maintain proper airflow and prevent contamination in the system.
- Drain Condensate: Regularly empty the condensate drain to prevent moisture buildup and ensure effective moisture removal.
- Inspect Connections: Check all hoses and connections for leaks or damage and tighten or replace components as needed.
- Monitor Pressure: Ensure the operating pressure remains within the specified range (232 PSI) for optimal performance and safety.
- Lubricate Moving Parts: Lubricate valves and other moving components according to the manufacturer’s instructions to reduce wear and tear.
- Test Functionality: Periodically test the air dryer to ensure it is operating as expected and cycling correctly for efficient air drying.
