Victron Centaur Charger - 24 VDC - 40AMP - 3-Bank - 120-240 VAC - CCH024040000 - CW82835

Victron Centaur Charger - 24 VDC - 40AMP - 3-Bank - 120-240 VAC - CCH024040000 - CW82835

The Centaur Charger delivers uncompromising quality and durability, designed to excel in harsh environments. Its robust aluminium epoxy powder-coated case with a drip shield and stainless steel fixings ensures resilience against heat, humidity, and salt air. The circuit boards are coated with acrylic to provide maximum corrosion resistance, and integrated temperature sensors monitor power components, adjusting the output current as needed to prevent overheating under extreme conditions. This charger operates efficiently across a wide input voltage range of 90-265V AC and is also compatible with a 90-400V DC supply, making it versatile for various power sources without requiring manual adjustments.

Equipped with three isolated outputs, the Centaur Charger can simultaneously charge up to three separate battery banks, each delivering the full rated current. It features a sophisticated three-stage charging process that includes bulk, timer, and float stages. The charger automatically switches to float mode after a 4-hour timer once the output drops to 70% of its rated amps. Temperature compensation ensures optimal charging performance by adjusting the voltage according to temperature changes, with a DIP switch allowing customization for different battery types such as Flooded Lead-acid, Gel, or AGM. This advanced design ensures reliable and efficient battery maintenance, enhancing both performance and longevity.

Features

• Quality without compromise - Aluminium epoxy powder coated cases with drip shield and stainless steel fixings withstand the rigors of an adverse environment: heat, humidity and salt air. Circuit boards are protected with an acrylic coating for maximum corrosion resistance. Temperature sensors ensure that power components will always operate within specified limits, if needed by automatic reduction of output current under extreme environmental conditions.

• Universal 90-265V AC input voltage range and also suitable for DC supply (AC-DC and DC-DC operation) All models will operate without any adjustment needed over a 90 to 265 Volt input voltage range, whether 50 Hz or 60 Hz.

• The chargers also accept a 90-400 V DC supply.

• Three outputs that each can supply the full output current Three isolated outputs to simultaneously charge 3 battery banks Each output is capable to supply the full rated current.

• Three-stage charging, with temperature compensation The Centaur charges at bulk rate until the output has reduced to 70% of the rated Amps, at which a 4 hour timer begins. After the timed period the charger switches to float rate. An internal temperature sensor is used to compensate the charge voltage with – 2 mV/ºC (– 1 mV/ºF) per cell. A DIP switch is available to select the optimum charge/float voltages for Flooded Lead-acid, Gel or AGM batteries

Specifications

What Our Experts Think

• Efficient Charging: Provides fast, efficient charging with a 40A output, ensuring your batteries are charged quickly and safely, maximizing their lifespan.
• Multi-Bank Capability: Designed to charge up to three different battery banks simultaneously, making it ideal for RVs, boats, and other multi-battery systems.
• Wide Voltage Range: Supports both 120-240 VAC input voltage, offering flexibility for use in different regions and power setups.
• High-Quality Build: Features a robust and durable construction, ensuring long-term performance even in demanding environments.
• Advanced Protection: Equipped with over-temperature and short-circuit protection to keep your batteries and charger safe during operation.
• Easy Installation: The compact design and clear instructions make it straightforward to install and integrate into your existing battery system.

Q&A

Q: What is the Victron Centaur Charger used for?
A: The Victron Centaur Charger is designed to charge 24 VDC battery systems with multiple banks, ideal for marine, RV, or off-grid applications.

Q: How many banks can the Centaur Charger support?
A: It can charge up to 3 battery banks simultaneously.

Q: What is the charging capacity of the Victron Centaur Charger?
A: The charger provides 40 amps of charging power.

Q: What input voltage does the Centaur Charger support?
A: It supports a wide input range of 120-240 VAC, making it versatile for various power sources.

Q: Is the Centaur Charger easy to install?
A: Yes, it is designed for easy installation with clear connections and a compact design suitable for various setups.

Q: Does the Victron Centaur Charger include safety features?
A: Yes, it includes overvoltage, overcurrent, and thermal protection for safe and efficient charging

Maintenance Tips

• Regular Cleaning: Keep the charger clean and dust-free. Use a soft, dry cloth to wipe down the exterior. Avoid using harsh chemicals or solvents that could damage the unit.

• Check Power Connections: Periodically inspect the input and output connections for any signs of wear, corrosion, or loose wiring. Tighten any loose connections and ensure they are free from dust or moisture.

• Inspect Cooling Vents: Ensure the cooling vents and fans are clear of obstructions and dirt to maintain proper airflow. Cleaning the vents will help prevent overheating and ensure optimal performance.

• Monitor Battery Charging: Regularly check the battery charging status to ensure it is operating correctly. Confirm that the charger is properly charging the batteries and that all bank connections are functioning as expected.

• Test Functionality: Perform regular tests to ensure that the charger is charging all three battery banks efficiently. Check the voltage levels and ensure they are within the manufacturer’s recommended range.

• Check for Software/Hardware Updates: If the charger has any software features or firmware updates, ensure you check for and apply the latest updates to maintain performance and compatibility with any new technology.

• Inspect for Overheating: Ensure the charger operates within its recommended temperature range. Avoid placing the unit in locations where heat can accumulate, such as enclosed spaces without ventilation.

• Periodic Inspection: Conduct a periodic check on the charger’s internal components for any signs of wear or damage, especially after extended use, and replace any worn-out parts as needed.
