Victron Energy MultiPlus 12/2000 80-50 120V - PMP122200102 - CW97092

Victron Energy  MultiPlus 12/2000 80-50 120V - PMP122200102 - CW97092

MultiPlus 12/2000 80-50 120V VE.Bus UL Listed

The MultiPlus, as the name suggests, is a combined inverter and charger in one elegant package. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology, plus multiple system integration features.

Unique PowerAssist Feature

The MultiPlus will prevent the overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shoreside supply with power taken from the battery.

Uninterrupted AC Power (UPS function)

In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption.

Virtually Unlimited Power Thanks to Parallel Operation

Up to 6 Multis can operate in parallel to achieve higher power output. Three-phase or split-phase operation is also possible. Please check our datasheets to see which models have parallel, three-phase, and split-phase capabilities.

Remote Monitoring & Control

When coupled with a GX device (e.g. Cerbo GX) you can monitor and control your Multi and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop, or PC for multiple operating systems. There is no end to the level of control, from adjusting your Multi to auto-starting a backup generator and more.

Features

• True Sine Wave Inverter: Provides high-quality AC power, suitable for all types of appliances and sensitive electronics.
  • Adaptive Charging: The adaptive charging technology optimizes the charging process, extending battery life and improving efficiency.
• Hybrid PowerAssist Technology: Prevents overload of limited AC sources such as generators or shore power connections. It reduces battery charging to prevent overload and can also boost the output using power from the battery when needed.
• Uninterrupted AC Power (UPS Function): In the event of a grid failure or disconnection from shore or generator power, the inverter seamlessly takes over within less than 20 milliseconds, ensuring continuous operation for connected devices.

Specifications

What Our Experts Think

• Powerful Inverter/Charger: With a 2000W output and 80A charging capacity, this device combines both a powerful inverter and charger into a single unit, ensuring efficient power conversion and battery charging.
• Dual Functionality: The MultiPlus not only inverts DC to AC power but also charges your batteries, making it an all-in-one solution for power management.
• Seamless Power Transfer: Equipped with a transfer switch, it allows for uninterrupted power supply, switching automatically between shore power and battery power.
• Advanced Protection: Features built-in protection for over-voltage, over-temperature, and overload, ensuring safe and reliable operation.
• Energy-Efficient: Designed to minimize energy loss, providing cost-effective power management while maintaining optimal system performance.
• Remote Monitoring: Supports remote monitoring and control via the VictronConnect app, allowing you to track and adjust settings from your mobile device.

Q&A

Q: What is the Victron Energy MultiPlus 12/2000 80-50 120V used for?
A: The MultiPlus is a combined inverter and charger, ideal for use in off-grid systems, RVs, boats, and other applications requiring AC power from a DC source.

Q: What are the key features of the MultiPlus?
A: It provides 12V DC to 120V AC inversion, with 2000VA (2000W) output, and includes an 80A battery charger. It also supports power assist and shore power integration.

Q: What is the maximum output capacity of the MultiPlus?
A: The inverter has a peak output of 2000W, and it can handle surges from devices like refrigerators and pumps.

Q: Is it suitable for use with solar systems?
A: Yes, it can be integrated into solar systems, providing power conversion from batteries, and managing energy storage and usage efficiently.

Q: Does the Victron Energy MultiPlus have smart features?
A: Yes, it features Bluetooth connectivity for remote monitoring and control via the Victron Energy app.

Q: Is it easy to install?
A: Yes, the MultiPlus is designed for easy installation, with clear wiring instructions and compatibility with various battery and power setups.

Q: Does it have built-in safety features?
A: Yes, it includes protections for overvoltage, undervoltage, overcurrent, and temperature extremes to ensure safe operation

Maintenance Tips

• Regular Cleaning: Keep the MultiPlus unit clean by wiping it down with a dry, soft cloth. Ensure that dust and dirt do not accumulate around the ventilation grilles, as this can affect the performance and cooling.

• Check Ventilation: Ensure the unit is installed in a well-ventilated area to prevent overheating. Keep airflow unrestricted around the unit to maintain efficient cooling. Clean any vents or air intakes to avoid dust buildup.

• Inspect for Damage: Regularly check for signs of wear, loose connections, or damage to the unit, wiring, or terminals. Tighten any loose connections and ensure there are no exposed or frayed wires.

• Monitor Battery Voltage: Ensure the connected batteries are operating within their recommended voltage range. Overcharging or undercharging the batteries can reduce their lifespan and affect the performance of the MultiPlus.

• Test Functionality: Perform periodic functional tests to ensure that the inverter and charger are operating properly. Check if the MultiPlus is successfully converting DC to AC power and properly charging the connected batteries.

• Check the Charging Settings: Review and adjust the charging parameters if needed. Make sure the charging settings are appropriate for your battery type and configuration to prevent overcharging or improper charging.

• Firmware Updates: If applicable, check for firmware updates for the MultiPlus and apply them. Regular updates will help improve performance and maintain compatibility with new technology.

• Avoid Overloading: Do not exceed the inverter’s power rating (2000W continuous power), as this can cause overheating and damage to internal components. Ensure that the load does not exceed the recommended limits.
