Victron Energy MultiPlus-II 12/3000 120-50 2X 120V - PMP122305100 - CW89145

Victron Energy MultiPlus-II 12/3000 120-50 2X 120V - PMP122305100 - CW89145

MultiPlus-II 12/3000 120-50 2X 120V

The MultiPlus-II combines the functions of the MultiPlus and the MultiGrid. It has all the features of the MultiPlus, plus an external current transformer option to implement PowerControl and PowerAssist and to optimize self-consumption with external current sensing (max. 32A).

It also has all the features of the MultiGrid with built-in anti-islanding and an increasingly long list of country approvals.

PowerAssist

The MultiPlus-II will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery.

ESS: Energy Storage Systems

The MultiPlus-II is the key component in a Victron ESS system, providing the flexibility to combine with MPPT Solar Chargers or Grid-tie PV Inverters. For examples and more detailed information see the ESS (Energy Storage System) manual.

Uninterrupted AC power (UPS function)

In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption.

Remote Monitoring and Control

When coupled with a GX device (e.g. Cerbo GX) you can monitor and control your Multi and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop, or PC for multiple operating systems. There is no end to the level of control, from adjusting your Multi to auto-starting a backup generator and more.

Features

• PowerAssist Technology: Prevents overload of limited AC sources by automatically reducing battery charging and boosting generator or shore power output with battery power.

• Advanced ESS Integration: Key component for Victron Energy Storage Systems (ESS), allowing seamless integration with MPPT Solar Chargers and Grid-tie PV Inverters for optimized self-consumption and energy management.

• Uninterrupted AC Power (UPS Function): Automatically activates the inverter in less than 20 milliseconds during grid failures or power loss, ensuring continuous operation of connected equipment.

• External Current Transformer Option: Enables PowerControl and PowerAssist functions with external current sensing (max. 32A) for enhanced system optimization.

• Anti-Islanding Protection: Built-in feature to comply with grid standards and ensure safe operation with a growing list of country approvals.

• Remote Monitoring & Control: Connect with a GX device (e.g., Cerbo GX) for local or remote monitoring and control via the free VRM app and portal. Access and adjust settings from any phone, tablet, laptop, or PC.

Specifications

What Our Experts Think

• Dual Output Capability: 3000VA inverter with 120V dual outputs, providing flexibility for split-phase applications.
• Powerful Charging: Integrated 120A battery charger ensures rapid and efficient energy replenishment.
• Automatic Transfer Switching: 50A transfer switch enables seamless transitions between power sources for uninterrupted operation.
• Pure Sine Wave Output: Protects sensitive electronics with stable and clean power delivery.
• System Integration: VE.Bus compatibility allows advanced monitoring and control with Victron accessories.

Q&A

Q: What is the Victron Energy MultiPlus-II 12/3000 Inverter/Charger (PMP122305100)?
A: A versatile 12V inverter/charger offering 3000VA output, dual 120V AC outputs, a 120A battery charger, and a 50A transfer switch for seamless power management.

Q: What are its key features?
A:

• Inverter Output: 3000VA with dual 120V AC outputs for powering a range of appliances.
• Battery Charger: 120A multi-stage charger for efficient battery maintenance.
• Transfer Switch: 50A automatic switch ensures uninterrupted power transitions.
• Grid-Assist Capability: Supports feed-in, backup, and off-grid operation.
• VE.Bus Compatibility: Allows for parallel operation and three-phase configurations.
• Compact Design: Durable and space-saving for diverse installations.

Q: Who is it ideal for?
A: Designed for RVs, boats, hybrid energy systems, off-grid setups, and backup applications requiring dual 120V outputs.

Q: Why choose this inverter/charger?
A: It delivers advanced functionality, reliable performance, and flexible energy management for complex power systems

Maintenance Tips

• Inspect Terminals: Regularly check AC/DC terminals for secure and corrosion-free connections.
• Monitor System: Use the VictronConnect app or VE.Bus to track performance and adjust configurations.
• Clean Vents: Keep air vents free of dust to maintain cooling efficiency and prevent overheating.
• Update Firmware: Update firmware through VE.Bus for optimal performance and access to new features.
• Test Transfer Switch: Periodically test the dual 50A transfer switch functionality for reliable power transitions.
• Optimize Charging: Configure the charger to match your battery specifications for safe and efficient charging.
• Secure Installation: Mount in a dry, ventilated area, avoiding moisture, extreme temperatures, and vibrations.
