Victron Energy Phoenix Inverter - 12VDC - 3000VA - 120VAC - 50/60Hz -PIN123020100 - CW82608

Victron Energy Phoenix Inverter - 12VDC - 3000VA - 120VAC - 50/60Hz -PIN123020100 - CW82608

Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz

Pure sine wave output, high peak power and high efficiency. Combined high frequency and line frequency technologies ensure the best of both worlds.

SinusMax - Superior engineering

Developed for professional duty, the Phoenix range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimised efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem free, to any load.

Extra start-up power

A unique feature of the SinusMax technology is very high start-up power. Conventional high frequency technology does not offer such extreme performance. Phoenix inverters, however, are well suited to power up difficult loads such as refrigeration compressors, electric motors and similar appliances.

Parallel and 3-phase operation capability

Up to 6 Phoenix Inverters can operate in parallel to achieve higher power output. Six 24V 5000VA units, for example, will provide 24kW / 30kVA output power. Operation in 3-phase configuration is also possible.

Communications interface

These larger Phoenix inverter models come with a VE.Bus port. All you need to connect to your PC is our MK3-USB VE.Bus to USB interface (see under accessories). Together with our VictronConnect or VEConfigure software, which can be downloaded free of charge from our website, parameters of the inverters can be customized. This includes output voltage and frequency, over and under voltage settings and programming the relay. This relay can for example be used to signal several alarm conditions, or to start a generator. The inverters can also be connected to a GX device (eg Cerbo GX) for monitoring and control.

Features

• Inverter and Charger Combined:
  • Dual Functionality: Integrates the features of a high-performance inverter and a smart charger in a single unit.
• PowerAssist Technology:
  • Overload Protection: Prevents overload of limited AC sources such as generators or shore power connections. It reduces battery charging to avoid overload and boosts output using battery power when necessary.
• ESS (Energy Storage Systems):
  • Flexible Integration: Acts as a core component in a Victron ESS system, compatible with MPPT Solar Chargers or Grid-tie PV Inverters for efficient energy storage and usage.
• Uninterrupted Power Supply (UPS) Function:
  • Seamless Transition: Automatically switches to inverter mode in the event of a grid failure or disconnection from shore or generator power, ensuring continuous power supply to connected loads within 20 milliseconds.

Specifications

What Our Experts Think

• High Power Capacity: 3000VA inverter designed to handle large loads and demanding applications in off-grid, marine, or RV systems.
• Pure Sine Wave Technology: Delivers clean, stable power suitable for sensitive electronics and appliances.
• Versatile Frequency: Supports both 50Hz and 60Hz, making it adaptable for various regions and devices.
• Durable Build: Engineered for long-term reliability with robust components and efficient cooling.
• Compact Design: Lightweight and easy to install, perfect for tight spaces.

Q&A

Q: What is the Victron Energy Phoenix Inverter 12V 3000VA (PIN123020100)?
A: A high-capacity pure sine wave inverter that converts 12V DC to 120V AC, delivering 3000VA for reliable power in off-grid and backup energy systems.

Q: What are its key features?
A:

• Inverter Output: 3000VA pure sine wave for powering sensitive electronics and high-demand appliances.
• Input Voltage: Operates on 12V DC systems.
• Output Voltage: Provides 120V AC at 50/60Hz for global compatibility.
• High Efficiency: Maximizes energy use from batteries.
• Robust Design: Durable construction for marine, RV, and off-grid applications.

Q: Who is it ideal for?
A: Designed for off-grid solar systems, RVs, boats, and backup applications requiring a powerful and reliable 12V to 120V AC solution.

Q: Why choose this inverter?
A: It combines high output capacity, pure sine wave quality, and versatile compatibility, making it a reliable choice for critical energy needs

Maintenance Tips

• Cooling System: Ensure the inverter's ventilation is unobstructed; clean the fan and vents regularly to prevent overheating.
• Battery Connection: Check the 12VDC input connections for tightness and corrosion; clean and secure as needed.
• Load Management: Avoid overloading; adhere to the 3000VA capacity to ensure stable operation.
• Firmware Updates: Update firmware periodically via Victron tools to access improvements and bug fixes.
• Environmental Protection: Install in a dry, dust-free location with proper ambient temperature (0–40°C).
• Wiring: Inspect AC and DC wiring for wear or damage, replacing faulty cables immediately.
• Performance Testing: Test functionality periodically to confirm the inverter switches smoothly between 50/60Hz output.
