Phoenix Inverter 12/3000 - 230V - VE. BUS

Pure sine wave output, high peak power and high efficiency. Combined high frequency and line frequency technologies ensure the best of both worlds.

SinusMax - Superior Engineering

Developed for professional duty, the Phoenix range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimised efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem free, to any load.

Parallel & 3-Phase Operation Capability

Up to 6 Phoenix Inverters can operate in parallel to achieve higher power output. Six 24V 5000VA units, for example, will provide 24kW / 30kVA output power. Operation in 3-phase configuration is also possible.

Features

• Pure Sine Wave Output: Ensures clean, stable power for sensitive electronics and appliances, free from interference and distortion.

• High Peak Power: Capable of delivering high power surges, accommodating demanding loads with ease.

• High Efficiency: Engineered to optimize energy use, reducing waste and maximizing performance.

• SinusMax Technology: Superior engineering designed for professional-grade applications. The hybrid HF (high frequency) technology results in a compact, lightweight inverter that delivers reliable performance without compromising on power quality.

• Parallel Operation Capability: Up to 6 Phoenix Inverters can be connected in parallel to achieve higher power outputs. For example, six 24V 5000VA units can deliver up to 24kW / 30kVA of power.

• 3-Phase Operation: Supports three-phase configurations for applications requiring balanced and efficient power distribution.

Specifications

What Our Experts Think

• Powerful Output: Delivers 3000VA of pure sine wave power, suitable for sensitive electronics and demanding equipment.
• Flexible Voltage Compatibility: Converts 12V DC to 230V AC, supporting 50/60Hz frequency for global applications.
• VE.Bus Integration: Allows seamless connection with Victron's system for advanced monitoring, control, and system expansion.
• High Efficiency: Minimal energy loss ensures prolonged battery life and reduced operational costs.
• Compact and Durable Design: Lightweight yet rugged, ideal for residential, marine, and mobile setups.
• Scalable System: Supports parallel and three-phase configurations for larger power needs.

Q&A

Q: What is the input voltage for this inverter?
A: It operates on 12VDC input voltage.

Q: What is the power output capacity?
A: It delivers a continuous output of 3000VA.

Q: What is the output voltage and frequency?
A: It provides 230VAC output at 50/60Hz, configurable based on requirements.

Q: Does it support VE.Bus connectivity?
A: Yes, it includes VE.Bus for system integration and remote monitoring.

Q: What are the key features?
A: Pure sine wave output, high efficiency, remote configuration, and parallel or three-phase operation capabilities.

Q: What are its typical applications?
A: Perfect for off-grid power, backup systems, and applications requiring reliable AC output.

Maintenance Tips

• Ventilation: Keep cooling vents and fans clean and unobstructed to prevent overheating.
• Connections: Inspect DC (12V) and AC (230V) terminals regularly for tightness and corrosion; clean as needed.
• Load Management: Avoid exceeding the 3000VA load capacity to ensure stable and efficient operation.
• Firmware Updates: Update firmware via the VE.Bus interface to maintain compatibility and access new features.
• Environmental Placement: Operate in a dry, dust-free area within the recommended temperature range (0–40°C).
• Battery Care: Use compatible 12V batteries and monitor charge levels to prevent deep discharges.
• Cable Inspection: Regularly check all wiring for wear or damage and replace faulty cables immediately.
• System Testing: Periodically test the 50/60Hz switching and VE.Bus communication to ensure optimal functionality.
